Product Details:
|
| Name: | Weichai Generator Sets | Feature: | High Reliability, Low Emissions, Low Noise |
|---|---|---|---|
| Key Selling Points: | High Performance | Emission Standards: | State IV |
| Cooling Method: | Closed Fan-radiator Cooling | Speed Governor: | ECU |
| Speed: | 1500r/min | No. Of Cylinder: | 4/6 |
| MODEL | STANDBY POWER | PRIME POWER | FUEL CONSUMPTION@75% LOAD |
ENGINE | |||||
| MODEL | RATED Power |
DISPLACEMENT | GOVERNOR | ||||||
| KVA | KW | KVA | KW | L/h | KW | L | |||
| WPG17L1^ | 17 | 14 | 15 | 12 | 3 | WP2.3D20E200 | 18 | 2.3 | Elec |
| WPG22L1^ | 22 | 18 | 20 | 16 | 4 | WP2.3D25E200 | 23 | 2.3 | Elec |
| WPG28L1^ | 28 | 22 | 25 | 20 | 5 | WP2.3D33E200 | 30 | 2.3 | Elec |
| WPG33L1^ | 33 | 26 | 30 | 24 | 5 | WP2.3D33E200 | 30 | 2.3 | Elec |
| WPG38L1 | 38 | 30 | 35 | 28 | 6 | WP2.3D40E200 | 36 | 2.3 | Elec |
| WPG44L1 | 44 | 35 | 40 | 32 | 7 | WP2.3D48E200 | 44 | 2.3 | Elec |
| WPG55L1 | 55 | 44 | 50 | 40 | 8 | WP2.3D53E200 | 48 | 2.3 | ECU |
Widely used in telecommunications, oil, public buildings, community, industrial and mining enterprises, hotels, hospitals and other fields.
Low noise, the noise level can reach 80dB (A) @ 1m or less;
Power reserve, and has good technical performance indicators;
DC12V electrical system;
High temperatures and rotating parts complete protection;
High-performance shock absorbers and 40 ℃ hot tank;
Spray Public chassis;
Rated power: 12KW-32KW
Rated voltage: 400V;
Rated speed / rated frequency: 1500rpm/50Hz;
Rated power factor: 0.8 (lagging);
Number of cylinders / Bore / Stroke: 4/89mm/92mm;
Displacement: 2.3L
Cooling: Closed radiator fan forced cooling;
Start mode: DC12V electric motor;
Phase number and connection: three-phase four-wire, star connection;
Excitation / regulator: Brushless / AVR automatically;
Diesel fuel consumption economy: ≤ 210g/kW · h;
Oil consumption: ≤ 1.1g/kW · h;
